SOS16 - Glycol In Transmission Oil Sample Kit
Sample kit suitable for Oil analysis, including additional Water by Karl Fischer and Glycol tests.
How do I take a good sample?
This kit contains the following items
Analysis included
- Elemental Analysis
-
Copper, Iron, Chromium, Lead, Aluminium, Silicon, Tin, Nickel, Sodium, Potassium, Molybdenum, Calcium, Magnesium, Phosphorus, Zinc, Titanium, Antimony, Vanadium, Boron, Sulfur, Silver, Manganese, Cadmium, Barium, Lithium.
- Viscosity
-
@40 Degrees Celcius.
- Physical Testing
- Karl Fischer Analysis
-
Water (ppm).
- FTIR
-
Oxidation, Nitration, Hydroxyl Group.
- Ferrous Content
-
PQ Index.
- Particle Count
-
ISO Cleanliness via ISO 4406.2, >4, >6, >10, >14, >18, >21, >38 and >50 Micron channel counts.
- Glycol
-
Glycol in Oil (ASTM 2982)
Before taking a sample
In addition to what is contained in your Sample Kit, You will need one of the following items in order to take your sample. If your machine is fitted with a live sampling point, you will need to use the live sampling probe. Otherwise, if you wish to take the sample through the dipstick tube, you should use the vacuum pump that is suitable for your working environment.
